Exhaust Fan E-DUC-1010 (1/2 hp)

Performance Data Model E-DUC1010

2050 CFM

115v 1 phase 60hz

1/2 hp

1725 rpm

18x18 base

PRODUCT SPECIFICATIONS Description/Application

 • Low Profile Centrifugal Up Blast Extractors are designed not just for restaurants but also for Food Truck Industry.

• Specifically designed for handling deep frying equipment and expelling grease, excessive heat, and smoke vertically.

CONSTRUCTION

 • Light Aluminum 1060 Body construction and Blower made of Aluminum 3003 H14.

 • 18 gauge galvanized iron base to withstand air pressure on bolts in the roof curb, designed to endure movement during transit.

• Impeller Construction: Heavy Gauge Aluminum Blade to resist the High Static Pressure.

• Waterproof Electrical Connection in the Lower Part of the Fan for easy Connections.

• Air-tight oil and water drain for efficient maintenance. Standard Equipment/Features • Die-Cast Heavy 4” Duty hub.

• Keyed 5/8” motor shaft with set screw for secure attachment

. • All serviceable parts are accessible from one Side of the unit.

• Quiet and dynamically balanced for efficient and smooth operation.

• Permanent run capacitor motor.
• Equipped with one of the world's best motors.
• Warranty: Includes a 2-year replacement warranty for added assurance.
